For reasons of backward compatibility some commands are implemented as ‘no operation’ NOP.

Table 14 summarizes the Drive command set with the paragraphs that follow describing the individual

commands and the task file for each.

Table 14: ATA Command Set (1)

Command

Code

FR

SC

SN

CY

DH

LBA

Check Power Mode

E5h or 98h

D

Erase Sector(s) (CFA)

C0h

Y

Y

Y

Y

Y

Execute Drive Diagnostic

Flush cache

Identify Drive

90h

E7h

ECh

D

D

D

Idle

Idle Immediate

NOP

Read Buffer

E3h or 97h

E1h or 95h

00h

E4h

Y

D

D

D

D

Read DMA

Read Multiple

C8

C4h

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Read native max address

F8h

D

Read Sector(s)

Read Verify Sector(s)

20h

40h or 41h

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Request Sense (CFA)

Security Disable Password

Security Erase Prepare

Security Erase Unit

Security Freeze Lock

Security Set Password

Security Unlock

03h

F6h

F3h

F4h

F5h

F1h

F2h

D

D

D

D

D

D

D

Set Features

EFh

Y

D

Set max address (with set password)

F9h

Y

Y

Y

Y

Y

Set Multiple Mode

C6h

Y

D

S.M.A.R.T.

B0h

Y

Y

Y

D

Stand By

Stand By Immediate

E2h or 96h

E0h or 94h

D

D

Translate Sector

87h

Y

Y

Y

Y

Y

Write Buffer

E8h

D

Write DMA

Write Multiple

Write Multiple w/o Erase (CFA)

Write Sector(s)

Write Sector(s) w/o Erase (CFA)

CA

C5h

CDh

30h

38h

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

1.

FR = Features Register, SC = Sector Count Register, SN = Sector Number Register, CY = Cylinder Registers,

DH = Drive/Head Register, LBA = Logical Block Address Mode Supported (see command descriptions for use),

Y – The register contains a valid parameter for this command. For the Drive/Head Register Y means both the Drive and head

parameters are used.

D – only the Drive parameter is valid and not the head parameter C – the register contains command specific data (see

command descriptors for use).

Swissbit AG

Industriestrasse 4

Swissbit reserves the right to change products or specifications without notice.

Revision: 1.41

CH-9552 Bronschhofen

Switzerland

www.swissbit.com

industrial@swissbit.com

F-100_data_sheet_CA-HxBR_Rev141.doc
